Intel CM238 Chipset

Description

Intel® Trusted Execution Technology. Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.. Intel® Virtualization Technology for Directed I/O (VT-d). Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.. Intel® ME Firmware Version. Intel® Management Engine Firmware (Intel® ME FW) uses built-in platform capabilities and management and security applications to remotely manage networked computing assets out-of-band.. Intel vPro® Platform Eligibility. The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.. Intel® Rapid Storage Technology. Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.. Intel® HD Audio Technology. Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.. Intel® Optane™ Memory Supported. Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.. RAID Configuration. RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a single logical unit, and distributes data across the array defined by RAID levels, indicative of the level of redundancy and performance required.. Intel® Smart Sound Technology. Intel® Smart Sound Technology is an integrated digital signal processor (DSP) for audio offload and audio/voice features. Intel® Smart Response Technology. Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive.. Intel® Platform Trust Technology (Intel® PTT). Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.. Intel® Standard Manageability. Intel® Standard Manageability is a base set of manageability features, including: Boot Control, Power State Management, HW Inventory, Serial Over LAN, and Remote Configuration.. Intel® Stable IT Platform Program (SIPP). The Intel® Stable IT Platform Program (Intel® SIPP) aims for zero changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity for IT to effectively manage their computing endpoints.. Intel® Boot Guard. Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.. Features. Product series. Intel® C230 Series Chipsets. Supports overclocking. No. Status. Launched. Supported RAID configuration. PCIe 0,1 / SATA 0,1,5,10. Bus speed. 8 GT/s. Product codename. Skylake. PCI Support. No. Launch date. Q1’17. Embedded options available. Yes. Thermal Design Power (TDP). 3.67 W. ECC. Yes. Number of displays supported. 3. System bus rate. 8 GT/s. Use conditions. Industrial Commercial Temp, PC/Client/Tablet, Embedded Broad Market Commercial Temp. Package size. 23 x 23 mm. Market segment. Mobile. On-board graphics card. No. Lithography. 22 nm. Processor special features. Intel® Smart Sound Technology. Yes. Intel® Smart Response Technology. Yes. Intel Stable Image Platform Program (SIPP). Yes. Intel® High Definition Audio (Intel® HD Audio). Yes. Intel Rapid Storage Technology enterprise. Yes. Intel Virtualization Technology for Directed I/O (VT-d). Yes. Intel Trusted Execution Technology. Yes. Intel ME Firmware Version. 11.6. Intel Clear Video Technology. Yes. Intel Rapid Storage Technology. Yes. Intel® Optane™ Memory Ready. Yes. Intel® Boot Guard. Yes. Intel® Platform Trust Technology (Intel® PTT). Yes. Intel® vPro™ Platform Eligibility. Yes. Ports & interfaces. PCI Express slots version. 3.0. Maximum number of PCI Express lanes. 20. USB ports quantity. 14. USB 2.0 ports quantity. 14. USB 3.2 Gen 1 (3.1 Gen 1) ports quantity. 10. Number of SATA III connectors. 8. USB version. 2.0/3.2 Gen 1 (3.1 Gen 1). Logistics data. Harmonized System (HS) code. 8542310001. Export Control Classification Number (ECCN). 5A992.C. Commodity Classification Automated Tracking System (CCATS). G147881
